Blue-and-White Porcelain
This case compares two front-view images of the same Blue-and-White Porcelain object. The comparison examines how lighting conditions affect pattern visibility, colour stability, surface reflection, object-background separation, and ceramic materiality.
Control Condition
Direct bilateral softbox lighting was used as the baseline condition. This image provides a bright and evenly illuminated record, but strong reflection can obscure the blue decoration, alter colour perception, and weaken the separation between the white porcelain body and the background.
Variable Condition
The lighting condition was adjusted using a diffuser and ceiling bounce lighting. This condition reduces direct reflection and makes the blue decoration, colour contrast, and object outline more stable.
Blue-and-White Porcelain: Control Condition Front View
Blue-and-White Porcelain: Variable Condition Front View
1. Quantitative Paradata: Technical Requirement
This table compares the technical and physical conditions under which the two images were produced.
| Category | Control Condition | Variable Condition |
|---|---|---|
| Image role | Control condition image | Variable condition image |
| View type | Front view | Front view |
| Lighting type | Bilateral softbox lighting | Diffused lighting with ceiling bounce lighting |
| Light distance | Approximately 1 m from the object | Approximately 1 m from the object on the left and right sides |
| Incident method | Direct light from left and right softboxes | Diffused light and indirect light reflected from the ceiling |
| Auxiliary device | Not used | Diffuser and ceiling reflective surface |
| Camera setting | Not recorded | ISO 100 / f/11 / 1/125s / 50mm |
| File generation | RAW-derived cropped JPEG image | RAW-derived cropped JPEG image |
| Colour profile | sRGB | sRGB |
2. Qualitative Paradata: Reproduction Note
This table compares the interpretive and observational notes recorded for each image.
| Category | Control Condition | Variable Condition |
|---|---|---|
| Photographic intention | This image was produced as a control condition image to provide a baseline for comparison with the variable condition image. Direct bilateral softbox lighting was used to record the overall form, white porcelain body, and blue decoration under a consistent lighting arrangement. | This image was produced to reduce strong reflections and to record the boundaries, colour, and brushwork of the blue decoration more consistently. It also aimed to improve the visual separation between the white porcelain body and the background. |
| Problem recognition | Direct bilateral softbox lighting produced strong highlights on the glazed surface. These highlights overlapped parts of the blue decoration, reduced pattern visibility, and caused the cobalt-blue pigment to appear brighter. The similar brightness of the porcelain body and background also weakened the object outline. | The control condition showed that direct illumination caused local highlights, partial loss of pattern visibility, colour distortion, and weak object-background separation. |
| Adjustment process | No corrective adjustment was applied. The bilateral softbox arrangement, direct incident light, and approximately 1 m lighting distance were retained as the control condition. | A diffuser was used to soften and spread the light before it reached the object. The frontal light was redirected toward the ceiling to create bounce lighting and reduce direct illumination on the glazed surface. |
| Visual observation | The image appears bright and evenly illuminated, but reflected highlights partially obscure the blue decoration. The cobalt-blue areas appear relatively bright, while the outer edge of the white porcelain body is not clearly separated from the background. | Strong highlights are reduced. The boundaries and brushwork of the blue decoration appear clearer, the cobalt-blue colour is more stable, and the porcelain outline is more clearly separated from the background. |
| Interpretive significance | The image demonstrates that high and even illumination does not necessarily produce a sufficient visual record. Direct reflection can reduce pattern legibility, alter colour perception, and weaken object-background distinction. | The comparison demonstrates that pattern visibility, colour stability, and boundary recognition depend on the structure and incident method of the lighting. |
Interpretation
The comparison demonstrates that the difference between the two images is not merely a matter of brightness or aesthetic preference. In the control condition image, direct bilateral softbox lighting produces strong highlights that obscure parts of the blue decoration, alter the perceived brightness of the cobalt-blue pigment, and weaken the separation between the white porcelain body and the background.
In the variable condition image, diffusion and ceiling bounce lighting reduce direct reflection and allow the pattern boundaries, brushwork, colour contrast, and object outline to be perceived more consistently. The visible difference results from a change in the conditions of image production rather than a change in the ceramic object itself.
Full Media Records
The full media records provide the complete metadata and paradata for each image.
